CORNER-TYPE CABLE ROLLER (GROUND PLATE)

CORNER-TYPE CABLE ROLLER (GROUND PLATE)

Product Code: GCC-CRC2

GCC-CRC2 Corner-Type Cable Roller Ground Plate is a durable guiding roller designed to safely guide and redirect cables around corners and direction changes during installation. It supports smooth and controlled cable movement while preventing the cable from rubbing against the ground or sharp edges. Its precision roller system minimizes friction and ensures stable cable guidance without twisting, excessive bending, or surface damage. The ground plate structure and fully galvanized body provide excellent stability, corrosion resistance, and long service life under outdoor working conditions.

Applications

• Guiding cables around corners and direction changes in underground and overhead projects
• Cable routes requiring smooth, stable, and low-friction guidance at turning points
• Heavy-duty cable laying operations where cable protection and controlled direction change are critical

Technical Specifications

• Maximum cable diameter: 160 mm
• Dimensions (L × W × H): 370 × 325 × 270 mm
• Weight: 13 kg
• Roller material: Delrin, Polyurethane, or metal (steel) (specify at order)
• Body coating: Fully Galvanized Body

Roller Material Options

• Delrin: Long service life, corrosion-resistant, low-friction, quiet operation, and gentle on cable sheaths and indoor floors
• Polyurethane: Excellent wear resistance, high load capacity, shock-absorbing, and non-marking, ideal for both indoor and outdoor applications
• Metal (steel): Maximum impact and abrasion resistance for rugged sites, sharp edges, and heavier cables
